Description
Description
This Premium Clear PETG Sheet offers exceptional properties including high impact strength, excellent fire rating, and is fully recyclable. Its lightweight construction makes it highly versatile, while its weather resistance ensures durability in various conditions. With extreme break resistance even at low temperatures, this material is ideal for a range of applications.
The sheets are designed for easy fabrication and feature superior thermoforming properties. They can be rapidly thermoformed at low temperatures, which results in low energy consumption and short production cycles. This efficiency not only saves time but also reduces costs. Additionally, they can be printed using standard screen printing equipment, significantly outperforming acrylic in cross hatch tests.
This Premium Clear PETG Sheet allows almost unlimited design freedom for creating three-dimensional parts. Typical applications include:
- Point of sale displays
- Direction signs
- Food containers and trays
- Flat and formed machine coverings
- Partitions
For further information regarding machined or finished components made from this premium material, please inquire directly.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PETG |
| Shape | Sheet |
| Colour | Clear 099 |
| Density (g/cm³) | 1.27 |
| Water absorption (%) | 0.2 |
| Yield stress (MPa) | 45 |
| Elongation at break (%) | 35 |
| Tensile modulus of elasticity (MPa) | 2020 |
| Notched impact strength (kJ/m²) | 6 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term max (°C) | 65 |
| Heat deflection temperature (°C) | 63-70 |
| Melting temperature (°C) | 80 |
| Thermal conductivity (W/(m*K) | 0.2 |
| Dielectric strength (kV/mm) | 16.1 |
| Volume resistivity (Ω*cm) | 10¹⁵ |
| Surface resistivity (Ω) | 10¹⁵ |
| Dielectric constant | 2.6 |
| Material type | Extruded |
FAQ
- Can this sheet be used outdoors? Yes, the Premium Clear PETG is weather resistant, making it suitable for outdoor applications.
- Is the material easy to print on? Yes, it can be printed with standard screen printing equipment.
- What are the temperature limits for this material? The service temperature long term max is 65°C, with a heat deflection temperature of 63-70°C.
