The Premium Clear Acrylic Cast Tube is an optically perfectly clear, highly polished product. It boasts excellent resistance to mechanical stress, a wide thermoforming range, and good thermal stability. The long-term service temperature range of Cast Acrylic is from -20°C to 80°C, making it an ideal material for various applications.
Typical fields of application for the Clear Acrylic Cast Tube include:
- Set design for film and TV
- Retail display solutions
- Aquarium and fish tank design
Clear Acrylic is well-suited to fabrication, gluing, and CNC turning, providing numerous options for custom solutions.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acrylic |
| Shape | Tube |
| Colour | Clear |
| Density (g/cm³) | 1.19 |
| Water absorption (%) | 0.21 |
| Elongation at break (%) | 3 |
| Thermal conductivity (W/(m*K)) | 0.19 |
| CLTE (10⁻⁶K⁻¹) | 70 |
| Service temp long term min (°C) | -20 |
| Service temp long term max (°C) | 80 |
| Dielectric constant | 2.9 |
| Dielectric strength (kV/mm) | 35 |
| Volume resistivity (Ω*cm) | >10¹⁵ |
| Material type | Cast |
Thick Wall Tubes
Thick wall tubes are double-cast, meaning a second tube is cast inside the first to achieve the desired thickness. While this maintains the physical properties of single-cast tubes, optical distortion and tolerance issues may result. Complaints about the quality of double-cast tubes are not accepted.
Applies to sizes:
- Outside diameter 60-100mm, wall thickness 8, 10, 12 & 15mm
- Outside diameter 110-610mm, wall thickness 12 & 15mm
FAQ
-
What is the temperature range for this acrylic tube?
The long-term service temperature range is from -20°C to 80°C. -
Can the acrylic be easily fabricated?
Yes, it is well suited for fabrication, gluing, and CNC turning. -
What applications are ideal for this acrylic tube?
It is ideal for set design, retail displays, and aquarium designs.
