Description
This premium pullbraided carbon fibre tube provides an ultra-light yet exceptionally strong structural solution for precision applications. Manufactured from high-performance carbon fibre with a consistently smooth outer finish, it offers excellent stiffness and rigidity while keeping weight to an absolute minimum.
Available in a range of outside diameters from 4 mm to 14 mm, wall thicknesses from 0.75 mm to 1.5 mm, and supplied in 2 x 2500 mm or 5000 mm lengths, this tube is ideal for electronics housings, lightweight frames, robotic arms, gimbals and other high-tech assemblies where strength, low mass and a clean aesthetic are crucial.
Product Features
- Outside diameter options: 4 mm, 5 mm, 6 mm, 8 mm, 10 mm, 12 mm and 14 mm to suit a wide variety of design requirements.
- Wall thickness choices of 0.75 mm, 1 mm and 1.5 mm for fine tuning weight, stiffness and load capacity.
- Length options of 2 x 2500 mm segments or a continuous 5000 mm tube for flexible cutting and minimal joints.
- Pullbraided carbon fibre construction for consistent fibre alignment and reliable, repeatable performance.
- Ultra-lightweight structure delivering high stiffness-to-weight and strength-to-weight ratios.
- Smooth external finish for low friction movement and an attractive, professional appearance.
- Supplied as raw tube ready for cutting, drilling and bonding into custom electronic and robotic assemblies.
Key Features and Benefits
- Reduces overall assembly weight, improving speed, efficiency and battery life in robotics and mobile systems.
- High tensile strength and rigidity support accurate, low-deflection motion for precision mechanisms and sensors.
- Pullbraided lay-up offers excellent dimensional stability and repeatability for batch or series production.
- Smooth carbon surface is easy to clean and ideal for applications where a neat, technical appearance is important.
- Multiple diameters, wall thicknesses and lengths simplify design selection and help minimise material waste.
- Good machinability with appropriate tools, enabling custom cuts, slots and holes to integrate with fittings and end-effectors.
Specifications
| Specification | Detail |
|---|---|
| Outside diameter range | 4 mm, 5 mm, 6 mm, 8 mm, 10 mm, 12 mm, 14 mm |
| Wall thickness options | 0.75 mm, 1 mm, 1.5 mm |
| Available lengths | 2 x 2500 mm segments or 5000 mm continuous tube |
| Material | Pullbraided carbon fibre composite |
| Finish | Smooth external surface, as-produced |
| Typical use temperature | Suitable for most ambient and elevated industrial environments (non-flame-critical applications) |
Applications and Ideal Uses
This carbon fibre tube is particularly suited to lightweight structural and protective roles in advanced electronic and robotic systems, as well as other precision engineering projects.
- Robotic arms, joints and linkages where low weight and high stiffness are essential.
- Electronics enclosures, sensor mounts and instrument supports.
- Lightweight frames for drones, gimbals, camera rigs and stabilisers.
- Automation equipment, gantries and linear motion assemblies.
- Prototype and custom engineering projects requiring compact, strong tubular sections.
Frequently Asked Questions
Can I cut the carbon fibre tube to shorter lengths myself?
Yes, the tube can be cut to size using suitable tools such as a fine-toothed saw or abrasive cutting wheel. It is recommended to tape the cutting area to minimise fraying and to wear appropriate personal protective equipment, including eye and respiratory protection, when cutting or sanding.
Is this carbon fibre tube suitable for outdoor or industrial environments?
The tube is suitable for most outdoor and industrial environments, as carbon fibre offers good resistance to moisture and corrosion. For prolonged exposure to UV or harsh chemicals, additional coatings or protective finishes may be advisable depending on the specific operating conditions.
How do I join or fix the tube to other components?
The tube can be joined using suitable adhesives, bonded inserts, mechanical clamps or custom machined fittings. Many users bond end-fittings or connectors into the tube using structural adhesives and then mechanically fasten those fittings into their assemblies, ensuring even load distribution and secure fixation.
