Description
Description
This Premium Pressed and Planed Black Sheet is a high-performance virgin polyethylene known for its exceptional characteristics, including high abrasion resistance, low coefficient of friction, and high impact strength. The sheet maintains dimensional stability in humid environments with a water absorption factor of <0.01%. It is ideal for applications requiring durability and reliability.
The long-term service temperature range of this black sheet is from -50°C to 80°C, with a short-term maximum service temperature of 130°C. This makes it suitable for a variety of conditions, ensuring consistent performance in both cold and hot environments.
Typical fields of application include bottling and food processing, mechanical engineering, bearing, and packing industries. This sheet is also well-suited for CNC routing, CNC milling, and CNC turning, making it a versatile choice for manufacturers.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PE1000 (UHMWPE) |
| Shape | Sheet |
| Colour | Black |
| Density (g/cm³) | 0.93 |
| Yield stress (MPa) | 20 |
| Elongation at break (%) | >200 |
| Shore hardness (scale D) | 63 |
| Tensile modulus of elasticity (MPa) | 680 |
| Melting temperature (°C) | 135 |
| Thermal conductivity (W/(m*K) | 0.4 |
| Thermal capacity (kJ/(kg*K) | 1.9 |
| CLTE (10⁻⁶K⁻¹) | 150…230 |
| Service temperature long term min (°C) | -50 |
| Service temperature long term max (°C) | 80 |
| Service temperature short term max (°C) | 130 |
| Heat deflection temperature (°C) | 79 |
| Dielectric constant | 2.3 |
| Dielectric strength (kV/mm) | 45 |
| Volume resistivity (Ω*cm) | >10¹⁴ |
| Surface resistivity (Ω) | >10¹⁴ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
Applications
- Bottling and food processing
- Mechanical engineering
- Bearing and packing industries
- CNC routing, milling, and turning
FAQs
-
What is the temperature range for this material?
The long-term service temperature range is from -50°C to 80°C. -
What industries can use this sheet?
It is suitable for bottling, food processing, mechanical engineering, and more. -
Can this material be machined?
Yes, it is well-suited for CNC routing, milling, and turning.
