Description
Description
The Premium High-Performance Beige PPC Sheet is designed to provide exceptional durability and versatility in various industrial applications. This sheet exhibits high strength, high heat resistance, and impressive chemical resistance, making it suitable for demanding environments.
With a long-term service temperature range from -30°C to 100°C, and a short-term maximum service temperature of 150°C, this material is ideal for applications in chemical engineering, tank building, and ventilation manufacturing. It can also be easily machined, CNC routed, welded, and fabricated.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PPC |
| Shape | Sheet |
| Colour | Beige |
| Density (g/cm³) | 0.91 |
| Yield stress (MPa) | 23 |
| Elongation at break (%) | >50 |
| Notched impact strength (kJ/m²) | >40 |
| Shore hardness (scale D) | 69 |
| Tensile modulus of elasticity (MPa) | 1100 |
| Melting temperature (°C) | 165 |
| Thermal conductivity (W/(m*K) | 0.2 |
| Thermal capacity (kJ/(kg*K) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term min (°C) | -30 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 150 |
| Heat deflection temperature (°C) | 85 |
| Dielectric constant | 2.5 |
| Dielectric strength (kV/mm) | 45 |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material type | Pinseal |
Applications
- Chemical Engineering
- Tank Building
- Ventilation Manufacturing
FAQ
- What is PPC sheet made from? PPC sheet is made from high-performance polymer material.
- What temperature range can PPC sheet withstand? This sheet can withstand temperatures from -30°C to 100°C long term and up to 150°C short term.
- What are the benefits of using PPC sheet? High strength, heat resistance, and chemical resistance make it ideal for various industrial applications.
