Description
Description
The Premium Antistatic Food Grade Ivory Sheet is a high-performance engineering plastic known for its excellent static dissipative properties, high dimensional stability, and FDA food approval (177.2470). This material is designed to withstand long-term use with a maximum service temperature of 100°C and a melting temperature of 168°C. It features a volume resistivity of ≤10¹⁰Ω *cm and a surface resistivity of ≤10¹²Ω, making it suitable for various sensitive applications.
Common applications for this material include medical technology, aerospace engineering, and the electrical industry. The Premium Antistatic Food Grade Ivory Sheet is well-suited for CNC milling, CNC routing, and CNC turning, providing versatility in manufacturing processes.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acetal C |
| Shape | Sheet |
| Colour | Ivory |
| Density (g/cm³) | 1.41 |
| Water absorption (%) | 0.8 |
| Yield stress (MPa) | 56 |
| Elongation at break (%) | 25 |
| Ball indentation hardness (MPa) | 180 |
| Shore hardness (scale D) | 82 |
| Tensile modulus of elasticity (MPa) | 2670 |
| Melting temperature (°C) | 168 |
| Service temp long term min (°C) | 0 |
| Service temp long term max (°C) | 100 |
| Volume resistivity (Ω*cm) | ≤10¹⁰ |
| Surface resistivity (Ω) | ≤10¹² |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material type | Antistatic |
Applications
This Premium Antistatic Food Grade Ivory Sheet is ideal for use in:
- Medical technology
- Aerospace engineering
- Electrical industries
FAQ
Q: What are the static dissipative properties of this sheet?A: The sheet has a volume resistivity of ≤10¹⁰Ω *cm and a surface resistivity of ≤10¹²Ω, ensuring excellent static control.
Q: Can this material be machined?A: Yes, it is well-suited for CNC milling, CNC routing, and CNC turning.
Q: What is the maximum service temperature?A: The maximum long-term service temperature is 100°C.
