Description
Description
Premium Anti-Static Pressed and Planed Black Sheet is a high-performance polyethylene with remarkable characteristics including reduced dust accumulation, high wear resistance, and exceptional impact strength. This material is engineered to perform reliably in a variety of environments.
The long-term service temperature range of this polyethylene sheet ranges from -50°C to 80°C, with a short-term maximum service temperature of 130°C. With a water absorption factor of <0.01%, this sheet maintains dimensional stability even in humid conditions.
Typical applications for this polyethylene sheet include mechanical engineering, bearing and packing industries, as well as electrical and electronic sectors. The material is well-suited for CNC routing, CNC milling, and CNC turning, making it versatile for various machining processes.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PE1000 (UHMWPE) |
| Shape | Sheet |
| Colour | Black |
| Density (g/cm³) | 0.95 |
| Yield Stress (MPa) | 22 |
| Elongation at Break (%) | >200 |
| Shore Hardness (scale D) | 63 |
| Tensile Modulus of Elasticity (MPa) | 700 |
| Melting Temperature (°C) | 135 |
| Thermal Conductivity (W/(m*K)) | 0.4 |
| Thermal Capacity (kJ/(kg*K)) | 1.9 |
| CLTE (10⁻⁶K⁻¹) | 150…230 |
| Service Temp Long Term Min (°C) | -50 |
| Service Temp Long Term Max (°C) | 80 |
| Service Temp Short Term Max (°C) | 130 |
| Heat Deflection Temperature (°C) | 79 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material Type | Pressed/Planed Antistatic |
Applications
- Mechanical Engineering
- Bearing and Packing Industries
- Electrical and Electronic Industries
FAQs
-
What is the maximum service temperature for this sheet?
The maximum short-term service temperature is 130°C. -
Is this material suitable for CNC machining?
Yes, it is well-suited for CNC routing, milling, and turning. -
What is the water absorption factor?
The water absorption factor is less than 0.01%.
