Description
Description
The Premium Extruded Fluorescent Acrylic Yellow Rod is a high-performance acrylic product designed to provide exceptional luminance and light diffusion. This material features high rigidity and a glossy surface finish, making it suitable for various applications such as point of sale displays, LED lighting fixtures, and innovative furniture design.
Engineered for versatility, this acrylic rod is ideal for billeting, bonding, and CNC turning. Its unique properties allow for easy fabrication and forming, ensuring that it can meet diverse design requirements.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acrylic |
| Shape | Rod |
| Colour | Yellow |
| Density (g/cm³) | 1.19 |
| Water Absorption (mg) | 38 |
| Elongation at Break (%) | 4.5 |
| Notched Impact Strength (kJ/m²) | 1.6 |
| Thermal Conductivity (W/(m*K)) | 0.19 |
| CLTE (10⁻⁶K⁻¹) | 70 |
| Service Temp Long Term Max (°C) | 70 |
| Heat Deflection Temperature (°C) | 95 |
| Dielectric Constant | 2.8-3.7 |
| Dielectric Strength (kV/mm) | ~30 |
| Material Type | Extruded |
Applications
- Point of Sale Displays
- LED Lighting Fixtures
- Furniture Design
Frequently Asked Questions
-
What is the maximum service temperature for this acrylic rod?
The maximum long-term service temperature is 70°C. -
Can this acrylic rod be easily fabricated?
Yes, it can be easily bonded, fabricated, or formed. -
What are the key benefits of using this material?
It offers high rigidity, excellent light diffusion, and a glossy finish.
