Description
Description
Premium Acetal C Extruded Natural Rod is an engineering plastic that offers exceptional product characteristics, including high chemical resistance, high dimensional stability, and low moisture absorption. The long-term service temperature range of Acetal C Rod spans from -50°C to 100°C, with a short-term maximum service temperature of 140°C.
This versatile material is particularly suitable for numerous applications in mechanical engineering, electrical and electronic industries, and medical technology. Premium Acetal C Rod is ideal for processes such as billeting, precision grinding, and CNC turning.
Minimum Order Quantity
The minimum order quantity for Premium Acetal C Rod Offcuts is 10.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acetal C |
| Shape | Rod |
| Colour | Natural |
| Density (g/cm³) | 1.41 |
| Water absorption (%) | 0.2 |
| Yield stress (MPa) | 67 |
| Elongation at break (%) | 30 |
| Notched impact strength (kJ/m²) | 6 |
| Ball indentation hardness (MPa) | 150 |
| Shore hardness (scale D) | 81 |
| Tensile modulus of elasticity (MPa) | 2800 |
| Melting temperature (°C) | 165 |
| Thermal conductivity (W/(m*K) | 0.31 |
| Thermal capacity (kJ/(kg*K) | 1.5 |
| CLTE (10⁻⁶K⁻¹) | 110 |
| Service temp long term min (°C) | -50 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 140 |
| Heat deflection temperature (°C) | 110 |
| Dielectric constant | 3.8 |
| Dielectric strength (kV/mm) | 40 |
| Dielectric dissipation factor (50Hz) | 0.002 |
| Volume resistivity (Ω*cm) | 10¹³ |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
Applications
Premium Acetal C Rod is well suited for a variety of mechanical and electrical applications, ensuring longevity and reliability in demanding environments. Its ability to withstand high temperatures and resist chemicals makes it an excellent choice for precision components.
FAQ
-
What is the minimum order for Acetal C Rod Offcuts?
Minimum order quantity is 10. -
What are the typical applications of Acetal C Rod?
It is used in mechanical engineering, electrical industries, and medical technology. -
What temperature range can Acetal C Rod withstand?
The long-term service temperature is from -50°C to 100°C.
