Description
Description
The Premium Acetal C Natural Sheet is an engineering plastic designed for complex machining, cutting, and finishing requirements. This material boasts high chemical resistance, excellent dimensional stability, and low moisture absorption, making it an ideal choice for various applications in mechanical engineering, electrical and electronic industries, and medical technology.
With a long-term service temperature range from -50°C to 100°C and a short-term maximum service temperature of 140°C, this sheet is versatile and durable. It is well-suited for CNC routing, CNC milling, and CNC turning, ensuring precision and reliability in every application.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acetal C |
| Shape | Sheet |
| Colour | Natural |
| Density (g/cm³) | 1.41 |
| Water absorption (%) | 0.2 |
| Yield stress (MPa) | 67 |
| Elongation at break (%) | 30 |
| Notched impact strength (kJ/m²) | 6 |
| Ball indentation hardness (MPa) | 150 |
| Shore hardness (scale D) | 81 |
| Tensile modulus of elasticity (MPa) | 2800 |
| Melting temperature (°C) | 165 |
| Thermal conductivity (W/(m*K) | 0.31 |
| Thermal capacity (kJ/(kg*K) | 1.5 |
| CLTE (10⁻⁶K⁻¹) | 110 |
| Service temp long term min (°C) | -50 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 140 |
| Heat deflection temperature (°C) | 110 |
Applications
- Mechanical Engineering
- Electrical and Electronic Industries
- Medical Technology
FAQ
- What is Acetal C Sheet used for? Acetal C Sheet is used in mechanical engineering, electronics, and medical applications due to its durability and chemical resistance.
- What temperature can Acetal C withstand? It can withstand long-term service temperatures from -50°C to 100°C and short-term temperatures up to 140°C.
- Is Acetal C suitable for CNC machining? Yes, it is well-suited for CNC routing, milling, and turning processes.
