Enjoy huge savings on Premium Acetal C Natural Hollow Rod offcuts, with additional discounts for volume purchases! This engineering plastic features excellent characteristics including high chemical resistance, high dimensional stability, and low moisture absorption. The long-term service temperature range of the Premium Acetal C Hollow Rod is from -50°C to 100°C, with a short-term maximum service temperature of 140°C.
Typical fields of application for Premium Acetal C Hollow Rod include mechanical engineering, electrical and electronic industries, and medical technology. It is well-suited for billeting, precision grinding, and CNC turning.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acetal C |
| Shape | Hollow Rod |
| Colour | Natural |
| Density (g/cm³) | 1.41 |
| Water absorption (%) | 0.2 |
| Yield stress (MPa) | 67 |
| Elongation at break (%) | 30 |
| Notched impact strength (kJ/m²) | 6 |
| Ball indentation hardness (MPa) | 150 |
| Shore hardness (scale D) | 81 |
| Tensile modulus of elasticity (MPa) | 2800 |
| Melting temperature (°C) | 165 |
| Thermal conductivity (W/(m*K) | 0.31 |
| Thermal capacity (kJ/(kg*K) | 1.5 |
| CLTE (10⁻⁶K⁻¹) | 110 |
| Service temp long term min (°C) | -50 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 140 |
| Heat deflection temperature (°C) | 110 |
| Dielectric constant | 3.8 |
| Dielectric strength (kV/mm) | 40 |
| Volume resistivity (Ω*cm) | 10¹³ |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
Applications
- Mechanical Engineering
- Electrical and Electronic Industries
- Medical Technology
- Billeting
- Precision Grinding
- CNC Turning
Frequently Asked Questions
- What is the temperature range for this material? The long-term service temperature range is from -50°C to 100°C.
- Can this material be machined? Yes, it is well suited for machining processes like precision grinding and CNC turning.
- What are the chemical resistance properties? This material has high chemical resistance, making it ideal for various applications.
