Description
Description
Premium Acetal C Blue Sheet is an engineering plastic renowned for its exceptional properties, including high chemical resistance, high dimensional stability, and low moisture absorption. This versatile material is suitable for a broad range of applications in mechanical engineering, electrical and electronic industries, and medical technology.
The long-term service temperature range of the Premium Acetal C Sheet spans from -50°C to 100°C, with a short-term maximum service temperature of 140°C. This makes it an ideal choice for environments that require durability under varying temperature conditions. Whether CNC routing, CNC milling, or CNC turning, this material performs exceptionally.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acetal C |
| Shape | Sheet |
| Colour | Blue |
| Density (g/cm³) | 1.41 |
| Water absorption (%) | 0.2 |
| Yield stress (MPa) | 67 |
| Elongation at break (%) | 30 |
| Notched impact strength (kJ/m²) | 6 |
| Ball indentation hardness (MPa) | 150 |
| Shore hardness (scale D) | 81 |
| Tensile modulus of elasticity (MPa) | 2800 |
| Melting temperature (°C) | 165 |
| Thermal conductivity (W/(m*K) | 0.31 |
| Thermal capacity (kJ/(kg*K) | 1.5 |
| CLTE (10⁻⁶K⁻¹) | 110 |
| Service temp long term min (°C) | -50 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 140 |
| Heat deflection temperature (°C) | 110 |
| Dielectric constant | 3.8 |
| Dielectric strength (kV/mm) | 40 |
| Volume resistivity (Ω*cm) | 10¹³ |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
Applications and Benefits
- Ideal for mechanical engineering and electronic applications.
- Excellent chemical resistance ensures long-term reliability.
- Low moisture absorption minimizes dimensional changes.
- High-performance under varying temperature conditions.
- Well-suited for CNC machining processes.
FAQ
What is Acetal C Sheet used for?
Acetal C Sheet is commonly used in mechanical engineering, electrical applications, and medical technology due to its high durability and chemical resistance.
What are the temperature limits for Acetal C Sheet?
The long-term service temperature range is -50°C to 100°C, with a short-term maximum of 140°C.
Can Acetal C Sheet be machined?
Yes, Acetal C Sheet is well-suited for CNC routing, milling, and turning.
