Description
Description
The Premium Acetal C Black Sheet is an advanced engineering plastic known for its exceptional properties. This material features high chemical resistance, high dimensional stability, and low moisture absorption. It can withstand long-term service temperatures ranging from -50°C to 100°C, with a short-term maximum service temperature of 140°C. These qualities make it an ideal choice for various applications in mechanical engineering, electrical and electronic industries, and medical technology.
Acetal C Black Sheet is perfectly suited for precision machining processes such as CNC routing, CNC milling, and CNC turning. Its versatility and durability make it a preferred option for professionals seeking reliable material solutions.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acetal C |
| Shape | Sheet |
| Colour | Black |
| Density (g/cm³) | 1.41 |
| Water absorption (%) | 0.2 |
| Yield stress (MPa) | 67 |
| Elongation at break (%) | 30 |
| Notched impact strength (kJ/m²) | 6 |
| Ball indentation hardness (MPa) | 150 |
| Shore hardness (scale D) | 81 |
| Tensile modulus of elasticity (MPa) | 2800 |
| Melting temperature (°C) | 165 |
| Thermal conductivity (W/(m*K) | 0.31 |
| Thermal capacity (kJ/(kg*K) | 1.5 |
| CLTE (10⁻⁶K⁻¹) | 110 |
| Service temp long term min (°C) | -50 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 140 |
| Heat deflection temperature (°C) | 110 |
Applications
- Mechanical Engineering
- Electrical and Electronic Industries
- Medical Technology
FAQ
-
What are the benefits of using Acetal C Sheet?
It offers high chemical resistance, low moisture absorption, and excellent dimensional stability. -
Can this material be used for CNC machining?
Yes, it is well-suited for CNC routing, milling, and turning processes. -
What is the temperature range for Acetal C Sheet?
It can withstand long-term temperatures from -50°C to 100°C, with a short-term maximum of 140°C.
