Description
Description
The Premium ABS Natural Sheet is an engineering plastic known for its exceptional characteristics, including low moisture absorption, high noise absorption, and superior rigidity and stiffness. This material is designed to withstand a long-term service temperature range from -40°C to 80°C, with a short-term maximum service temperature of 100°C.
Common applications for the ABS Natural Sheet include vehicle construction, precision engineering, electrical industries, and sanitary engineering. It is particularly well-suited for CNC routing, CNC milling, and CNC turning, making it a versatile choice for various manufacturing processes.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | ABS |
| Shape | Sheet |
| Colour | Natural |
| Density (g/cm³) | 1.07 |
| Water absorption (%) | 0.3 |
| Yield stress (MPa) | 45 |
| Elongation at break (%) | 20 |
| Notched impact strength (kJ/m²) | 11 |
| Ball indentation hardness (MPa) | 90 |
| Shore hardness (scale D) | 78 |
| Tensile modulus of elasticity (MPa) | 2400 |
| Thermal conductivity (W/(m*K)) | 0.17 |
| Thermal capacity (kJ/(kg*K)) | 1.2 |
| CLTE (10⁻⁶K⁻¹) | 90 |
| Service temp long term min (°C) | -40 |
| Service temp long term max (°C) | 80 |
| Service temp short term max (°C) | 100 |
| Dielectric constant | 3.1 |
| Dielectric strength (kV/mm) | 20 |
| Volume resistivity (Ω*cm) | 10¹⁵ |
| Surface resistivity (Ω) | 10¹⁴ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
Applications
- Vehicle Construction
- Precision Engineering
- Electrical Industries
- Sanitary Engineering
FAQ
-
What is the temperature range for ABS Natural Sheet?
The long-term service temperature range is from -40°C to 80°C, with a short-term maximum of 100°C. -
Can ABS Natural Sheet be used for CNC machining?
Yes, it is well suited for CNC routing, milling, and turning. -
What industries commonly use ABS Natural Sheet?
It is widely used in vehicle construction, precision engineering, and sanitary engineering.
