Description
Description
The Premium ABS Matt White Sheet is a thermoformable sheet product known for its high rigidity and impact strength. It features excellent chemical and abrasion resistance, as well as superior moisture and creep resistance, making it ideal for a variety of applications.
This versatile material is commonly used in automotive industries, point of sale displays, and model making. Additionally, it is well-suited for CNC routing, vacuum forming, and bonding. The Premium ABS Sheet is a reliable choice for professionals seeking durability and performance.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | ABS |
| Shape | Sheet |
| Colour | White |
| Density (g/cm³) | 1.07 |
| Water absorption (%) | 0.3 |
| Yield stress (MPa) | 45 |
| Elongation at break (%) | 20 |
| Notched impact strength (kJ/m²) | 11 |
| Ball indentation hardness (MPa) | 90 |
| Shore hardness (scale D) | 78 |
| Tensile modulus of elasticity (MPa) | 2400 |
| Thermal conductivity (W/(m*K)) | 0.17 |
| Thermal capacity (kJ/(kg*K)) | 1.2 |
| CLTE (10⁻⁶K⁻¹) | 90 |
| Service temp long term min (°C) | -40 |
| Service temp long term max (°C) | 80 |
| Service temp short term max (°C) | 100 |
| Dielectric constant | 3.1 |
| Dielectric strength (kV/mm) | 20 |
| Volume resistivity (Ω*cm) | 10¹⁵ |
| Surface resistivity (Ω) | 10¹⁴ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
Applications
- Automotive Industries
- Point of Sale Displays
- Model Making
- CNC Routing
- Vacuum Forming
- Bonding
FAQ
What is ABS Sheet used for?
ABS Sheet is commonly used in automotive applications, point of sale displays, and model making due to its durability and impact resistance.
Can ABS be used for vacuum forming?
Yes, ABS is well-suited for vacuum forming, allowing for precise shaping and molding.
What are the temperature limits for ABS Sheet?
The service temperature range for ABS Sheet is from -40°C to 80°C for long-term use and up to 100°C for short-term applications.
