Description
Description
This premium 3D honeycomb composite sheet features a core made from melted polycarbonate straws in three different diameters, creating a lightweight yet rigid material ideal for many indoor applications. The straws are randomly melted into a cohesive block that is then shortened to the desired core thickness. The core is finished with glued cover sheets available in acrylic or PETG, depending on the required properties for specific applications.
The composite sheet is easy to cut and can be finished with standard accessories, such as profile frames, handles, hinges, and can also be edged with the same material as the external layers. It is available in clear gloss or clear satin finishes, providing versatility in aesthetic and functional applications.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PETG Honeycomb Composite |
| Shape | Sheet |
| Colour | Clear |
| Density (g/cm³) | 1.3 |
| Service temp long term min (°C) | -10 |
| Service temp long term max (°C) | 50 |
| E-modulus (MPa) | 2350 |
| COE (mm/m/10ºC) | 0.5 |
| Bending strength (kg/cm) | 1587 |
| Fire classification (EN13501-1) | Bs1D0 |
| Thickness tolerance | Barely |
| Saw tolerance (mm) | +/-1 |
| Deviation angularity (mm/1m) | 1.5 |
| Material type | Honeycomb |
Applications
This premium composite sheet is suitable for a variety of applications such as:
- Interior design projects
- Partitions and wall coverings
- Signage and displays
- Furniture manufacturing
FAQ
What is the maximum service temperature for this composite sheet?
The maximum service temperature is 50°C.
Can the composite sheet be cut to size?
Yes, it is easy to cut with standard tools and can be finished with various accessories.
What colors are available for this product?
The composite sheet is available in clear gloss or clear satin finishes.
