Description
Description
The PPH Extruded Natural Sheet is a high-performance material characterized by its exceptional strength, outstanding heat resistance, and strong chemical and corrosion resistance. This sheet is suitable for a temperature range of 0°C to 100°C for long-term use, with a short-term maximum service temperature of up to 150°C.
Typical applications for this natural sheet include chemical engineering, tank construction, and laboratory technology. Its properties make it an excellent choice for CNC routing, welding, and fabrication.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PPH |
| Shape | Sheet |
| Colour | Natural |
| Density (g/cm³) | 0.91 |
| Yield stress (MPa) | 32 |
| Elongation at break (%) | >50 |
| Notched impact strength (kJ/m²) | 4 |
| Shore hardness (scale D) | 72 |
| Tensile modulus of elasticity (MPa) | 1300 |
| Melting temperature (°C) | 167 |
| Thermal conductivity (W/(m*K) | 0.2 |
| Thermal capacity (kJ/(kg*K) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term min (°C) | 0 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 150 |
| Heat deflection temperature (°C) | 90 |
| Dielectric constant | 2.4 |
| Dielectric strength (kV/mm) | 45 |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material type | Extruded |
Applications
- Chemical Engineering
- Tank Building
- Laboratory Technology
FAQ
- What is the maximum service temperature? The maximum short-term service temperature is 150°C.
- Can this sheet be used for CNC routing? Yes, this material is well-suited for CNC routing and fabrication.
- What is the density of the PPH sheet? The density is 0.91 g/cm³.
