Description
Description
This High-Performance Polyester Backed Grey Sheet features exceptional strength, heat resistance, and chemical resistance, making it a reliable choice for various industrial applications. The material can be bonded with other substances and is suitable for machining processes such as CNC routing, welding, and fabrication.
The long-term service temperature range of this polyester backed sheet is from -30°C to 100°C, with a short-term maximum service temperature reaching up to 150°C. This versatility allows it to be used effectively in environments subjected to varying temperature conditions.
Typical Applications
- Chemical engineering
- Tank building
- Ventilation manufacturing
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PPC |
| Shape | Sheet |
| Colour | Grey |
| Density (g/cm³) | 0.91 |
| Yield stress (MPa) | 23 |
| Elongation at break (%) | >50 |
| Notched impact strength (kJ/m²) | >40 |
| Shore hardness (scale D) | 69 |
| Tensile modulus of elasticity (MPa) | 1100 |
| Melting temperature (°C) | 165 |
| Thermal conductivity (W/(m*K) | 0.2 |
| Thermal capacity (kJ/(kg*K) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term min (°C) | -30 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 150 |
| Heat deflection temperature (°C) | 85 |
| Dielectric constant | 2.5 |
| Dielectric strength (kV/mm) | 45 |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material type | Polyester Backed |
FAQ
- What is the service temperature range of the sheet? The long-term service temperature range is from -30°C to 100°C, with a short-term maximum of 150°C.
- What applications is this sheet suitable for? It is suitable for chemical engineering, tank building, and ventilation manufacturing.
- Can this sheet be bonded with other materials? Yes, it can be bonded with various materials for enhanced applications.
