The Premium Lubricant Filled Nylon 6 Red Sheet features a solid lubricant additive, making it particularly suitable for sliding applications. This material provides a sustainable lubricating effect throughout its entire life cycle, effectively reducing the undesirable stick-slip tendency.
Key characteristics of this product include:
- Excellent sliding properties
- Extraordinary wear resistance
- Low moisture absorption
- Dimensional stability
Typical applications encompass bearings, gears, slide/guide rails, actuators, feeder wheels, sprockets, curve guides, and chain guides. The Lubricant Filled Nylon 6 also complies with the requirements of EU Regulation Nr. 10/2011 and FDA requirement 21 DFR § 177.1500, making it suitable for components that come into direct contact with food.
This material is well-suited for CNC routing, CNC milling, and CNC turning. For any needs regarding machined or finished Nylon 6 components, please inquire for further information.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Nylon 6 |
| Shape | Sheet |
| Colour | Red |
| Density (g/cm³) | 1.14 |
| Water absorption (%) | 2.2 |
| Yield stress (MPa) | 80 |
| Elongation at break (%) | ≥40 |
| Notched impact strength (kJ/m²) | ≥4 |
| Ball indentation hardness (MPa) | 160 |
| Tensile modulus of elasticity (MPa) | 3100 |
| Melting temperature (°C) | 220 |
| Thermal conductivity (W/(m*K) | 0.23 |
| Thermal capacity (kJ/(kg*K) | 1.7 |
| Service temp long term min (°C) | -40 |
| Service temp long term max (°C) | 105 |
| Service temp short term max (°C) | 160 |
| Dielectric constant | 3.7 |
| Dielectric strength (kV/mm) | 50 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material type | Lubricant Filled |
Applications
This red sheet is ideal for a variety of industrial applications, including:
- Bearings
- Gears
- Slide/Guide Rails
- Actuators
- Feeder Wheels
- Sprockets
- Curve Guides
- Chain Guides
FAQ
Q: Can the Lubricant Filled Nylon 6 Red Sheet be used in food contact applications?
A: Yes, it meets the requirements of EU Regulation Nr. 10/2011 and FDA requirement 21 DFR § 177.1500, making it suitable for direct food contact.
Q: What machining processes are suitable for this material?
A: It is well-suited for CNC routing, CNC milling, and CNC turning.
Q: What is the maximum service temperature for short-term use?
A: The maximum service temperature for short-term use is 160°C.
