This Premium honeycomb composite sheet consists of a hexagonal aluminium core glued between two top layers of either acrylic or PETG, depending on the application. This ultra-lightweight material reflects and refracts light within the cells, creating a soft glow from within that moves as your point of view changes. Available in a range of colours with both transparent and satin finishes.
Being rigid and impact resistant, this composite sheet is excellent for use in partition walls, wall presentations, lighting fixtures, bar and counter fronts, stair panels, balustrades, doors, walls, and ceilings. It is easy to cut, can be finished with standard accessories and profiles, and can be edged with the same material used for the external layers. Please note that this material is not suitable for outdoor applications.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PETG Honeycomb Composite |
| Shape | Sheet |
| Colour | Light Fume |
| Density (g/cm³) | 1.3 |
| Service temperature long term min (°C) | -10 |
| Service temperature long term max (°C) | 50 |
| E-modulus (MPa) | 2350 |
| COE (mm/m/10ºC) | 0.5 |
| Bending strength (kg/cm) | 1587 |
| Fire classification (EN13501-1) | Bs1D0 |
| Thickness tolerance | Barely |
| Saw tolerance (mm) | +/-1 |
| Deviation angularity (mm/1m) | 1.5 |
| Material type | Honeycomb |
Applications
- Partition walls
- Wall presentations
- Lighting fixtures
- Bar and counter fronts
- Stair panels
- Balustrades
- Doors
- Walls and ceilings
FAQ
- Is this material suitable for outdoor use? No, this material is not suitable for outdoor applications.
- Can this material be cut easily? Yes, it is easy to cut and can be finished with standard accessories.
- What is the fire classification of this composite sheet? The fire classification is Bs1D0 according to EN13501-1.
