Description
Description
This Premium honeycomb composite sheet consists of a hexagonal aluminum core (large or small) glued between two top layers of either acrylic or PETG, depending on the application. This ultra-lightweight material reflects and refracts light within the cells, creating a soft glow from within that moves as your point of view changes. Available in a range of colors with both transparent and satin finishes.
Being rigid and impact resistant, this composite sheet is excellent for use in partition walls, wall presentations, lighting fixtures, bar- and counter fronts, stair panels, balustrades, doors, walls, and ceilings. It is easy to cut, can be finished with standard accessories and profiles, frames, handles, and hinges, and can be edged with the same material used for the external layers. However, this product is not suitable for outdoor applications.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acrylic |
| Shape | Sheet |
| Colour | Fume |
| Density (g/cm³) | 1.19 |
| Service temp long term min (°C) | -10 |
| Service temp long term max (°C) | 50 |
| E-modulus (MPa) | 3300 |
| COE (mm/m/10ºC) | 0.6 |
| Bending strength (kg/cm) | 1200 |
| Fire classification (EN13501) | E |
| Thickness tolerance | 0.4mm +/- 10% |
| Saw tolerance (mm) | +/-1 |
| Deviation angularity (mm/1m) | 1.5 |
| Material type | Honeycomb |
Applications
This Premium honeycomb composite sheet is perfect for:
- Interior partition walls
- Wall presentations
- Lighting fixtures
- Bar and counter fronts
- Stair panels
- Balustrades
- Doors
- Walls and ceilings
FAQ
Is this material suitable for outdoor use?
No, this composite sheet is not suitable for outdoor applications.
Can the sheet be easily cut?
Yes, it is easy to cut and can be finished with standard accessories and profiles.
What is the fire classification of this material?
The fire classification is E according to EN13501.
