Description
Description
This high-performance PEI filament is manufactured from premium polyetherimide resin, offering an exceptional combination of high mechanical strength, dimensional stability, and heat resistance. It is inherently flame retardant and classified UL94-V0, making it an excellent choice for demanding applications.
Raw Material Approvals
- Aerospace FAR25.853
Our filaments are produced from high-quality raw materials with close tolerances (+/- 0.05 mm), allowing for precise and failure-free 3D printing. They are low emission, odor-free, shrinkage-free, and provide good layer adhesion. Compatible with all standard 3D printers, each spool is carefully packed in resealable zip bags for easy use.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PEI |
| Shape | Printing Filament |
| Colour | Natural |
| Tolerances | +/- 0.05 mm |
| Density | 1.27 g/cm³ |
| Water Absorption | 0.25% |
| Service Temp Long Term Max | 170°C |
| Yield Stress | 110 MPa |
| Elongation at Break | 50% |
| Notched Impact Strength | 32 kJ/m² |
| Ball Indentation Hardness | 106 MPa |
| Tensile Modulus of Elasticity | 3350 MPa |
| Heat Deflection Temperature | 209°C |
| Thermal Conductivity | 0.22 W/(m*K) |
| Melting Temperature | 350-410°C |
| Pressure Nozzle Temperature | 370-390°C |
| Printing Plate Temperature | 150°C |
| Build Chamber Temperature | 90°C |
| Nozzle Diameter | 0.4 mm |
| Print Speed | 45 mm/s |
| Fan Speed | 0-25% |
| Predrying Temperature | 120°C |
FAQ
- What is the maximum service temperature for this filament? The maximum long-term service temperature is 170°C.
- Is this filament flame retardant? Yes, it is inherently flame retardant and classified UL94-V0.
- Can this filament be used with any 3D printer? Yes, it is compatible with all standard 3D printers.
