Description
Description
Our Professional Nylon recoil hoses are designed for effective conveying of compressed air or liquids over short distances. These spiral wound expandable lengths of Nylon tubing effortlessly return to their original size and shape when not in use, creating a tidy and hazard-free working environment.
Technical Specifications
The hoses come equipped with BSP swivel male connector fittings crafted from nickel-plated brass, complete with spring guards for added durability. An Nitrile Butadiene Rubber (NBR) O-ring with a 70 shore hardness ensures a reliable seal.
Features
- Material: Nylon
- Shape: Recoil Hose
- Compatible with various hose types including Nylon, Polythene, Polyurethane, and braided PVC hoses/tubes.
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| BSP Fitting Size (inches) | |
| 8 & 10mm OD | 1/4" |
| 12mm OD | 3/8" |
| Service Temperature Long Term Min (°C) | -20 |
| Service Temperature Long Term Max (°C) | 80 |
| Pressure Range (BAR) | -0.99 to 15 |
Applications
This recoil hose is ideal for a variety of applications including workshops, construction sites, and manufacturing environments where air or liquid conveyance is needed.
FAQ
- What is the maximum pressure rating for the hose? The hose can handle pressures ranging from -0.99 to 15 BAR.
- What is the service temperature range? The long-term service temperature range is between -20°C to 80°C.
- Can the hose be used with liquids? Yes, it is suitable for conveying both compressed air and liquids.
