Description
These high-performance roll wrapped carbon fibre tubes are engineered to deliver exceptional unidirectional strength along the length of the tube, making them ideal for demanding structural and mechanical applications. Manufactured from multiple layers of carbon fibre with a controlled fibre orientation, they provide a superior strength-to-weight ratio compared with traditional metal tubing.
Available in a wide choice of diameters, wall thicknesses and lengths, these tubes are suitable for everything from precision hobby projects and sporting equipment through to advanced industrial, robotics and aerospace prototypes. Their smooth outer finish and consistent internal bore make them easy to integrate with machined components, fittings and bonded assemblies.
Product Features
- Roll wrapped carbon fibre construction with unidirectional fibres for maximum longitudinal strength.
- Outside diameter options from 10 mm (pack of 2) and 12 mm (pack of 2) through 15 mm, 18 mm, 20 mm and many additional sizes to suit varied design requirements.
- Choice of wall thicknesses including 1.0 mm, 1.4 mm, 1.5 mm and 1.6 mm for optimised balance of stiffness, strength and weight.
- Standard tube lengths of 600 mm, 1000 mm, 1200 mm, 2000 mm and 2400 mm to minimise cutting and waste.
- High-modulus carbon fibre reinforcement with resin matrix for excellent rigidity and low mass.
- Smooth outer surface suitable for bonding, painting, clear coating or cosmetic finishing.
- Precision-manufactured internal bore for reliable fit with inserts, joints and mechanical fixings.
Key Features and Benefits
- Lightweight yet extremely strong, allowing replacement of heavier metal tubes to reduce overall system weight and improve performance.
- Excellent axial stiffness and tensile strength due to unidirectional fibre alignment, improving load-bearing capability in the primary direction of use.
- Corrosion-resistant construction that will not rust or degrade in moist or chemically aggressive environments, reducing maintenance needs.
- Low thermal expansion compared with metals, helping to maintain dimensional stability and alignment in temperature-sensitive assemblies.
- Easy to cut, drill and bond with appropriate tools and adhesives, offering flexibility during prototyping and custom builds.
- Available in a range of diameters, wall thicknesses and lengths, enabling precise specification for hobby, performance and industrial projects.
Specifications
| Specification | Detail |
|---|---|
| Material | Roll wrapped carbon fibre with polymer resin matrix |
| Outside diameter options | 10 mm (pack of 2), 12 mm (pack of 2), 15 mm, 18 mm, 20 mm and additional intermediate sizes |
| Wall thickness options | 1.0 mm, 1.4 mm, 1.5 mm, 1.6 mm (depending on diameter) |
| Standard lengths | 600 mm, 1000 mm, 1200 mm, 2000 mm, 2400 mm |
| Construction type | Unidirectional fibres in roll wrapped lay-up for axial strength |
| Finish | Smooth outer surface, suitable for bonding or cosmetic finishing |
Applications and Ideal Uses
Designed for advanced projects where low weight, high stiffness and precise dimensional control are essential, these carbon fibre tubes perform reliably in both hobbyist and professional environments.
- Robotics arms, frames and motion systems requiring high stiffness with minimal mass.
- Aerospace, drone and UAV structures such as booms, spars and fuselage elements.
- Sports and leisure equipment including spars, poles, shafts and high-performance frames.
- Automotive, motorsport and motorcycle components for brackets, supports and chassis elements.
- Precision engineering, camera rigs, jigs and fixtures where rigidity and low deflection are critical.
Frequently Asked Questions
Can these carbon fibre tubes be cut and drilled to custom sizes?
Yes, the tubes can be cut and drilled using appropriate tools, such as fine-toothed saws or abrasive cutting discs and carbide or diamond-tipped drill bits. It is recommended to support the tube during cutting, use dust extraction where possible and wear suitable personal protective equipment when working with carbon fibre dust.
Are these tubes suitable for outdoor and high-moisture environments?
Yes, the carbon fibre and resin matrix are corrosion-resistant and well suited to outdoor and high-moisture environments. For long-term exposure to UV and harsh weather, applying a protective clear coat or paint is recommended to help preserve the appearance of the surface.
How do I choose the right diameter and wall thickness for my application?
Select the smallest diameter and wall thickness that will safely handle the loads, deflection limits and connection requirements of your design. Larger diameters and thicker walls offer greater stiffness and strength but add weight. Checking expected forces, span lengths and mounting methods will help you choose from the available diameter, wall thickness and length options.
