Description
Description
The High-Performance Regen Pressed and Planed Black UHMWPE Sheet is a premium polyethylene material known for its remarkable characteristics. This sheet offers high chemical resistance, exceptional impact strength, and outstanding wear resistance, making it ideal for demanding applications.
With a long-term service temperature range of -50°C to 80°C and a short-term maximum service temperature of 130°C, this UHMWPE sheet is designed to perform in various environments. Its water absorption factor of less than 0.01% ensures dimensional stability even in humid conditions.
Typical applications for this UHMWPE sheet include drive and conveyor technology, harbor construction, and mechanical engineering. It is well-suited for CNC routing, CNC milling, and CNC turning, providing versatility in manufacturing processes.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PE1000 Regen (UHMWPE) |
| Shape | Sheet |
| Colour | Black |
| Density (g/cm³) | 0.94 |
| Yield stress (MPa) | 22 |
| Elongation at break (%) | >200 |
| Shore hardness (scale D) | 65 |
| Tensile modulus of elasticity (MPa) | 700 |
| Melting temperature (°C) | 135 |
| Thermal conductivity (W/(m*K)) | 0.4 |
| Thermal capacity (kJ/(kg*K)) | 1.9 |
| CLTE (10⁻⁶K⁻¹) | 150…230 |
| Service temperature long term min (°C) | -50 |
| Service temperature long term max (°C) | 80 |
| Service temperature short term max (°C) | 130 |
| Heat deflection temperature (°C) | 79 |
| Dielectric constant | 2.3 |
| Dielectric strength (kV/mm) | 45 |
| Volume resistivity (Ω*cm) | >10¹⁴ |
| Surface resistivity (Ω) | >10¹² |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
Applications
- Drive and conveyor technology
- Harbor construction
- Mechanical engineering
FAQs
-
What is the temperature range for this UHMWPE sheet?
This sheet has a long-term service temperature range from -50°C to 80°C and short-term maximum of 130°C. -
Can this material be machined?
Yes, it is suitable for CNC routing, CNC milling, and CNC turning. -
What are the benefits of using this material?
It offers high chemical resistance, impact strength, and low water absorption for dimensional stability.
