Description
Description
The Professional Extruded Black Sheet is engineered for high strength, heat resistance, and chemical resistance. It maintains a long-term service temperature range from -30°C to 100°C, with a short-term maximum service temperature of 150°C. This versatile material is perfect for a variety of applications including chemical engineering, tank building, and ventilation manufacturing.
This sheet is well suited for CNC routing, welding, and fabrication, making it an excellent choice for both prototyping and production needs.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PPC |
| Shape | Sheet |
| Colour | Black |
| Density (g/cm³) | 0.91 |
| Yield stress (MPa) | 23 |
| Elongation at break (%) | >50 |
| Notched impact strength (kJ/m²) | >40 |
| Shore hardness (scale D) | 69 |
| Tensile modulus of elasticity (MPa) | 1100 |
| Melting temperature (°C) | 165 |
| Thermal conductivity (W/(m*K)) | 0.2 |
| Thermal capacity (kJ/(kg*K)) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term min (°C) | -30 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 150 |
| Heat deflection temperature (°C) | 85 |
| Dielectric constant | 2.5 |
| Dielectric strength (kV/mm) | 45 |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material type | Extruded |
Applications
- Chemical engineering
- Tank building
- Ventilation manufacturing
- CNC routing and fabrication
- Welding
FAQ
What is the maximum service temperature for this sheet?The maximum short-term service temperature is 150°C.
Can this material be used in chemical environments?Yes, it has high chemical resistance, making it suitable for various chemical applications.
What machining processes can be applied to this sheet?This sheet can be CNC routed, welded, and fabricated easily.
