Description
Description
This high-performance 3D printing filament is a polyetherimide blend that delivers exceptional mechanical strength, dimensional stability, and heat resistance. It is inherently flame retardant and classified UL94-V0, making it ideal for demanding applications.
Raw Material Approvals
- Aerospace FAR25.853 and OSU55/55
- Rail EN45545 R6-HL3
Manufactured from high-quality materials with tight tolerances (+/- 0.05 mm), this filament ensures precise and reliable 3D printing. It is low emission, odor-free, and exhibits excellent layer adhesion. Compatible with all standard 3D printers, it is delivered carefully spooled and packed in resealable zip bags for convenience.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Polyetherimide Blend |
| Shape | Printing Filament |
| Colour | Natural |
| Tolerances (mm) | +/- 0.05 mm |
| Density (g/cm³) | 1.28 |
| Water absorption (%) | 0.15 |
| Service temp long term max (°C) | 170 |
| Yield stress (MPa) | 94 |
| Elongation at break (%) | 70 |
| Notched impact strength (kJ/m²) | 10 |
| Ball indentation hardness (MPa) | 115 |
| Tensile modulus of elasticity (MPa) | 2439 |
| Heat deflection temperature (°C) | 169 |
| Melting temperature (°C) | 330-350 |
| Pressure nozzle temperature (°C) | 360 |
| Printing plate temperature (°C) | 160 |
| Build chamber temperature (°C) | 90 |
| Nozzle diameter - hardened steel (mm) | 0.4 |
| Print speed (mm/s) | 45 |
| Fan speed - activated on layer 4 (%) | 30-35 |
FAQ
- What is the maximum service temperature for this filament? The maximum service temperature is 170°C.
- Is this filament compatible with all 3D printers? Yes, it is compatible with all standard 3D printers.
- What is the density of this filament? The density of the filament is 1.28 g/cm³.
