The High-Performance Fire Retardant Grey Sheet is designed for demanding applications, offering exceptional flame retardance, high rigidity, and very high chemical resistance. This premium material is suitable for various industrial needs, particularly in chemical engineering, equipment manufacture, and ventilation manufacturing.
With a long-term service temperature range from 0°C to 100°C and a short-term maximum service temperature of 150°C, this sheet can withstand challenging environments. Its suitability for CNC routing, welding, and fabrication makes it a versatile choice for custom projects.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PPS |
| Shape | Sheet |
| Colour | Grey |
| Density (g/cm³) | 0.94 |
| Yield stress (MPa) | 32 |
| Elongation at break (%) | >50 |
| Notched impact strength (kJ/m²) | 4 |
| Shore hardness (scale D) | 70 |
| Tensile modulus of elasticity (MPa) | 1300 |
| Melting temperature (°C) | 167 |
| Thermal conductivity (W/(m*K)) | 0.2 |
| Thermal capacity (kJ/(kg*K)) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term min (°C) | 0 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 150 |
| Heat deflection temperature (°C) | 81 |
| Dielectric constant | 2.3 |
| Dielectric strength (kV/mm) | >15 |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | V2 |
| Flammability 6mm | V2 |
| Material type | Fire Retardant |
Applications
- Chemical engineering
- Equipment manufacture
- Ventilation manufacturing
FAQ
- What is the maximum service temperature? The maximum service temperature for short-term use is 150°C.
- Is it suitable for CNC routing? Yes, this material is well-suited for CNC routing, welding, and fabrication.
- What applications can this sheet be used for? It is ideal for chemical engineering, equipment manufacture, and ventilation manufacturing.
