Description
Description
The Premium perforated natural sheet is a low-density, highly resistant material designed for various industrial applications. With exceptional impact strength and a long-term service temperature range of -20°C to 80°C, this sheet is ideal for welding and fabrication tasks. Its perforated design enhances versatility while maintaining structural integrity.
Important Note:
This product is manufactured using industrial processes, which may result in surface marks from tooling and material burrs around the perforations.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PPC |
| Shape | Sheet |
| Colour | Natural |
| Density (g/cm³) | 0.91 |
| Tensile Strength (MPa) | 23 |
| Elongation at Yield (%) | 7 |
| Notched Impact Strength (kJ/m²) | 45 |
| Shore Hardness (Scale D) | 67 |
| Tensile Modulus of Elasticity (MPa) | 1200 |
| CLTE (10⁻⁶K⁻¹) | 160 |
| Service Temperature Long Term Min (°C) | -20 |
| Service Temperature Long Term Max (°C) | 80 |
| Dielectric Strength (kV/mm) | 52 |
| Surface Resistivity (Ω) | 10¹³ |
FAQ
-
What is the temperature range for this sheet?
The sheet can withstand temperatures from -20°C to 80°C. -
Can this sheet be used for welding?
Yes, the material is suitable for welding and fabrication. -
Are there any visible marks on the surface?
Yes, due to the manufacturing process, surface marks and material burrs may be present.
