Description
Description
The Premium 3D Honeycomb Composite Sheet features a unique core constructed from melted polycarbonate straws in three different diameters. The straws are randomly melted together into a block, subsequently shortened to achieve the desired core thickness. This innovative design is then enhanced with glued cover sheets crafted from acrylic or PETG, tailored to meet specific application requirements.
Lightweight yet incredibly rigid, this composite sheet is ideal for a wide range of indoor applications. It is easy to cut and can be finished with standard accessories and profile frames, as well as handles and hinges. Additionally, it can be edged using the same material as the external layers, providing a seamless look. The sheet is available in both clear gloss and clear satin finishes, allowing for aesthetic flexibility.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Acrylic |
| Shape | Sheet |
| Colour | Clear |
| Density (g/cm³) | 1.19 |
| Service temp long term min (°C) | -10 |
| Service temp long term max (°C) | 50 |
| E-modulus (MPa) | 3300 |
| COE (mm/m/10ºC) | 0.6 |
| Bending strength (kg/cm) | 1200 |
| Fire classification (EN13501) | E |
| Thickness tolerance | 0.4mm +/- 10% |
| Saw tolerance (mm) | +/-1 |
| Deviation angularity (mm/1m) | 1.5 |
| Material type | Honeycomb |
Benefits
- Lightweight design for easy handling and installation
- High rigidity ensures durability in various applications
- Customizable finishes allow for aesthetic preferences
- Compatible with standard cutting tools and accessories for versatility
FAQ
Q: What are the available finishes for this composite sheet?A: The composite sheet can be ordered in clear gloss or clear satin finishes.
Q: What are the temperature limits for this material?
A: The long-term service temperature range is from -10°C to 50°C.
Q: Is this material easy to cut?
A: Yes, the sheet is easy to cut and can be finished with standard accessories.
