Polytetrafluoroethylene (PTFE) is a high-performance, synthetic fluoropolymer that offers exceptional characteristics including a very high working temperature, low friction surface, high electrical resistance, and non-stick properties. This range of PTFE tubing is specifically designed in American Wire Gauge (AWG) sizes for the insulation of standard wire and cable diameters.
Our PTFE tubing is available in various sizes including Imperial and metric options, as well as ultra-thin wall tubing with an inside diameter ranging from 0.2mm to 1.5mm and a very thin wall of only 0.1mm.
Please note: Coils may not be continuous lengths. If you require a continuous length, please specify this when you order.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PTFE |
| Shape | AWG Sleeve |
| Colour | Natural |
| Density (g/cm³) | 2.14-2.19 |
| Water absorption (%) | 0.01 |
| Yield stress (MPa) | 10 |
| Elongation at break (%) | 200-500 |
| Shore hardness (scale D) | 55-72 |
| Tensile modulus of elasticity (MPa) | 600-800 |
| Melting temperature (°C) | 327 |
| Thermal conductivity (W/(m*K) | 0.23 |
| Dielectric strength (kV/mm) | 40-80 |
| Arc resistance (sec) | >360 |
| Surface resistivity (Ω) | 10¹⁷ |
Frequently Asked Questions
-
What sizes are available for this PTFE AWG sleeving?
It is available in various AWG sizes suitable for standard wire and cable insulation. -
Can I request a continuous length of tubing?
If a continuous length is required, please specify this at the time of ordering. -
What are the key properties of PTFE tubing?
PTFE tubing features high temperature resistance, low friction, and excellent electrical insulation properties.
For additional specifications, please refer to the technical properties.
