Description
Description
The Premium Reinforced Clear Polyurethane Tube offers outstanding elasticity, providing excellent flexibility and kink resistance even at extremely low temperatures. With exceptional abrasion resistance and resistance to a wide range of chemicals, this tube is versatile enough to be suitable for various conveyance applications, including dry powders, granules, gases, and liquids.
This tube features excellent clarity, 85 Shore A hardness, and a service temperature range of -40°C to 65°C, remaining flexible even in low temperature environments. It is compliant with RoHS 3 standards, ensuring safety and environmental consideration.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | Polyurethane |
| Shape | Reinforced Flexible Tube |
| Service Temperature Long Term Min (°C) | -40 |
| Service Temperature Long Term Max (°C) | 65 |
Dimensions & Specifications
| Outside/Inside Diameter | Max Working Pressure (BAR) | Max Burst Pressure (BAR) |
|---|---|---|
| 12 / 6.3mm | 13 | 40 |
| 13.5 / 8mm | 11 | 33 |
| 15.75 / 10mm | 10 | 30 |
| 18.5 / 12.5mm | 7 | 21 |
Applications
- Conveyance of dry powders and granules
- Transport of gases and liquids
- Suitable for industrial and commercial use
FAQs
- What is the temperature range for this tube? The tube operates within a temperature range of -40°C to 65°C.
- Is this tube resistant to chemicals? Yes, it has exceptional resistance to a wide range of chemicals.
- What materials is the tube made of? The tube is made from high-quality polyurethane.
