Description
This Premium High-Performance Black PPC Sheet is designed with exceptional characteristics including high strength, high heat resistance, and high chemical resistance. The long-term service temperature range of this sheet is from -30°C to 100°C, with a short-term maximum service temperature of 150°C, making it suitable for diverse industrial applications.
Common fields of application for this PPC Sheet include chemical engineering, tank building, and ventilation manufacturing. It is also well-suited for processes involving CNC routing, welding, and fabrication.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PPC |
| Shape | Sheet |
| Colour | Black |
| Density (g/cm³) | 0.91 |
| Yield stress (MPa) | 23 |
| Elongation at break (%) | >50 |
| Notched impact strength (kJ/m²) | >40 |
| Shore hardness (scale D) | 69 |
| Tensile modulus of elasticity (MPa) | 1100 |
| Melting temperature (°C) | 165 |
| Thermal conductivity (W/(m*K) | 0.2 |
| Thermal capacity (kJ/(kg*K) | 1.7 |
| CLTE (10⁻⁶K⁻¹) | 120 |
| Service temp long term min (°C) | -30 |
| Service temp long term max (°C) | 100 |
| Service temp short term max (°C) | 150 |
| Heat deflection temperature (°C) | 85 |
| Dielectric constant | 2.5 |
| Dielectric strength (kV/mm) | 45 |
| Surface resistivity (Ω) | 10¹³ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
Applications
- Chemical Engineering
- Tank Building
- Ventilation Manufacturing
- CNC Routing
- Welding and Fabrication
FAQ
-
What is the temperature range for this PPC sheet?
The long-term service temperature range is from -30°C to 100°C, with a short-term maximum of 150°C. -
Can this material be used for CNC routing?
Yes, this sheet is well-suited for CNC routing, welding, and fabrication. -
What industries is this material suitable for?
It is ideal for chemical engineering, tank building, and ventilation manufacturing.
