Description
Description
The Premium ABS Extruded Natural Rod is a high-performance, amorphous thermoplastic known for its exceptional properties. This material features low moisture absorption, high noise absorption, and remarkable rigidity, making it suitable for a variety of applications.
The long-term service temperature range of this ABS Rod spans from -40°C to 80°C, with a short-term maximum service temperature reaching up to 100°C. Its robustness and stability make it an ideal choice for industries such as precision engineering, electrical sectors, sanitary engineering, and vehicle construction.
ABS Rod is well-suited for processes like billeting, precision grinding, and CNC turning, ensuring a high-quality finish in manufactured components.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | ABS |
| Shape | Rod |
| Colour | Natural |
| Density (g/cm³) | 1.07 |
| Water absorption (%) | 0.3 |
| Yield stress (MPa) | 45 |
| Elongation at break (%) | 20 |
| Notched impact strength (kJ/m²) | 11 |
| Ball indentation hardness (MPa) | 90 |
| Shore hardness (scale D) | 78 |
| Tensile modulus of elasticity (MPa) | 2400 |
| Thermal conductivity (W/(m*K) | 0.17 |
| Thermal capacity (kJ/(kg*K) | 1.2 |
| CLTE (10⁻⁶K⁻¹) | 90 |
| Service temp long term max (°C) | 80 |
| Service temp long term min (°C) | -40 |
| Service temp short term max (°C) | 100 |
| Dielectric constant | 3.1 |
| Dielectric strength (kV/mm) | 20 |
| Volume resistivity (Ω*cm) | 10¹⁵ |
| Surface resistivity (Ω) | 10¹⁴ |
| Comparative tracking index | 600 |
| Flammability 3mm | HB |
| Flammability 6mm | HB |
| Material type | Extruded |
Applications
- Precision engineering
- Electrical industries
- Sanitary engineering
- Vehicle construction
FAQ
-
What is the maximum service temperature of the ABS Rod?
The maximum short-term service temperature is 100°C. -
Is the ABS Rod suitable for CNC turning?
Yes, it is well-suited for CNC turning and precision grinding. -
What is the density of the ABS material?
The density of the ABS material is 1.07 g/cm³.
