Description
Description
This Premium Low Density Polyurethane (PU) model board is a cost-effective, lightweight solution with a density of 0.08g/cm³. It can be easily shaped by hand or CNC machined to produce composite models or patterns. Unlike PU foam, this model board offers a much finer and smoother surface, making it an excellent choice for detailed work.
The low density PU model board is versatile and can be shaped using conventional tools or machined with manual or CNC machines. However, it is important to note that it does not possess the strength or surface finish of higher density PU model boards, making it suitable for specific applications.
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Material | Low Density PU Model Board |
| Shape | Sheet |
| Colour | White |
| Density (g/cm³) | 0.08 |
| Compressive strength (MPa) | 0.75 |
| Flexural strength (MPa) | 1.2 |
| Elastic Modulus (MPa) | 24 |
| Service temp long term max (°C) | 120 |
| Service temp long term min (°C) | -80 |
| CLTE (10⁻⁶K⁻¹) | 70 |
Technical Specifications
- Material: Low Density Polyurethane
- Shape: Sheet
- Colour: White
- Density: 0.08 g/cm³
- Compressive Strength: 0.75 MPa
- Flexural Strength: 1.2 MPa
- Elastic Modulus: 24 MPa
- Maximum Long-term Service Temperature: 120 °C
- Minimum Long-term Service Temperature: -80 °C
- Coefficient of Linear Thermal Expansion: 70 x 10⁻⁶ K⁻¹
FAQs
-
Can this model board be used for CNC machining?
Yes, it is suitable for CNC machining as well as hand shaping. -
What is the max service temperature for this material?
The maximum long-term service temperature is 120 °C. -
Is this board suitable for detailed modeling?
Yes, it provides a fine and smooth surface ideal for detailed work.
