Description
Description
This Premium Electrically Conductive UHMWPE rod is a high-performance variant designed for enhanced electrical conductivity, with a surface resistance of ≤10⁶ Ω. It features remarkable characteristics such as high strength, stiffness, and rigidity even at low temperatures down to -40°C. Additionally, it exhibits excellent thermal and dimensional stability, making it suitable for demanding environments.
The rod also has very good sliding properties, minimal water absorption, and high resistance to solvents, enhancing its usability in various applications. Typical uses for this rod include earthing strips, flanges, sleeves, and components that come into contact with powder and dust.
Applications of this rod extend to billeting, precision grinding, and CNC turning, making it an ideal choice for precision machining tasks. For custom machined components, further inquiries are encouraged.
Technical Specifications
| Specification | Measurement |
|---|---|
| Material | PE1000 (UHMWPE) |
| Shape | Rod |
| Colour | Black |
| Density (g/cm³) | 0.93 |
| Water absorption (%) | 0 |
| Elongation at break (%) | >50 |
| Shore hardness (scale D) | 63 |
| Melting temperature (°C) | 135 |
| CLTE (10⁻⁶K⁻¹) | 200 |
| Service temp long term max (°C) | 90 |
| Volume resistivity (Ω*cm) | <10⁶ |
| Surface resistivity (Ω) | <10⁶ |
| Material type | ELS |
FAQ
- What applications is this rod suitable for? The rod is suitable for earthing strips, flanges, sleeves, and components in contact with powders and dust.
- Can this rod be machined? Yes, it is well suited for billeting, precision grinding, and CNC turning.
- What are the thermal properties of the rod? It has high rigidity at low temperatures down to -40°C and a long-term service temperature max of 90°C.
